Name: JMZ-T1-2.0 Spring Isolator with 1 Year Warranty for Industrial and Commercial Applications and High Shock Absorption
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JMZ-T1-2.0
Availability: InStock

Nhà > các sản phẩm > Máy cách ly mùa xuân >

JMZ-T1-2.0 Spring Isolator with 1 Year Warranty for Industrial and Commercial Applications and High Shock Absorption

1 Year Warranty Spring Isolator

Industrial and Commercial Application Vibration Isolator

High Shock Absorption Friction Damping Isolator

Nguồn gốc:

Trung Quốc

Hàng hiệu:

Hoan

Số mô hình:

JMZ-T1-2.0

Liên hệ với chúng tôi

Yêu cầu Đặt giá

JMZ-T1-2.0 Spring Isolator with 1 Year Warranty for Industrial and Commercial Applications and High Shock Absorption

Chi tiết sản phẩm

Khả năng tương thích:

Phù hợp với hầu hết các thiết bị tiêu chuẩn

Phong cách thiết kế:

Công nghiệp

Ứng dụng:

Công nghiệp và thương mại

Các thành phần cốt lõi:

Mang

BẢO TRÌ:

Bảo trì thấp

Loại gắn kết:

Vít-vào

Hấp thụ sốc:

Cao

Giảm tiếng ồn:

Đúng

Đặc trưng:

Bền, dễ cài đặt

Bảo hành:

1 năm

Màu sắc:

Bạc

Có sẵn:

Có sẵn rộng rãi

Làm nổi bật:

1 Year Warranty Spring Isolator

Industrial and Commercial Application Vibration Isolator

High Shock Absorption Friction Damping Isolator

Điều khoản thanh toán và vận chuyển

Số lượng đặt hàng tối thiểu

Điều khoản thanh toán

L/C, D/A, D/P, T/T, Liên minh phương Tây, Moneygram

Sản phẩm liên quan

JMZ-T1-1.4 32mm Overall Width Spring Isolator with 1 Year Warranty and High Resilience for Industrial Vibration Isolation

Nhận được giá tốt nhất

JMZ-T1-1.2 Spring Isolator with 95% Isolation Efficiency 32mm Overall Width and UL Listed for Vibration Isolation

Nhận được giá tốt nhất

JMZ-T1-0.6 Spring Isolator with High Resilience and Strong Shock Resistance for Durable Vibration Control

Nhận được giá tốt nhất

JMZ-T1-0.45 Friction Damping Vibration Isolator with Up to 95% Isolation Efficiency for 0-150°F Operating Temperature and 1 Year Warranty

Nhận được giá tốt nhất

Liên hệ với chúng tôi

86-29-88292913

Liên hệ ngay bây giờ

Mô tả sản phẩm

JMZ-T1-2.0 The Ultimate Solution for Equipment Stability and Performance with Spring Isolator

JMZ-T1 Series

Redefining Stability Boundaries: The JMZ-T Series transforms equipment performance foundations into strategic advantages by addressing the critical relationship between installation stability and ultimate accuracy.

In precision engineering, vibration acts as a "precision assassin" originating from both external sources (ground fluctuations, human movement) and internal equipment components. The JMZ-T Series friction damping vibration isolators from Xi'an Hoan Microwave Co., Ltd. go beyond traditional vibration reduction to redefine equipment stability boundaries, converting basic vibration isolation into a core strategic performance advantage.

Unlike traditional solutions (rubber pads or ordinary springs) that may trigger resonance or cause prolonged oscillation, the JMZ-T Series implements proactive "energy management" through:

Innovative multi-stage friction damping mechanism
Precisely controlled internal friction pairs
Efficient conversion of mechanical energy to thermal energy
Rapid stabilization for improved performance

This technology delivers measurable benefits for precision measuring instruments (faster reading stabilization, higher data repeatability) and high-end manufacturing equipment (superior processing consistency, lower scrap rates).

The JMZ-T Series represents a paradigm shift - not just a component, but a "performance amplifier" that unlocks equipment design potential by creating an ideal static working platform.

Structural Dimension Diagram

Technical Parameters

Model	Max PZ-Direction Load	PZ Displacement Under Max Load	H (mm)	h (mm)	d (mm)	Weight (g)	Shock Test	Resonance Frequency (Hz)	Operating Temp Range (℃)
JMZ-T1-0.3	0.3	≤0.6	19.5±0.5	16	M4-7H/ M3-7H	≤58	30g,11ms	＜30	-65～+120
JMZ-T1-0.45	0.45
JMZ-T1-0.6	0.6
JMZ-T1-1.2	1.2		22±0.5	17.5
JMZ-T1-1.4	1.4
JMZ-T1-2.0	2.0

Vibration Curve of JMZ-T1 Series

Impact Curve of JMZ-T1 Series
